Roll Cage Trolleys
Collapsible wire mesh roll cage trolleys engineered for retail distribution, e-commerce fulfilment, and in-plant material movement. Light weight and nestable, cutting reverse logistics costs while maximising usable floor space when not in use. Built from high-tensile mild steel with heavy-duty industrial castors rated for continuous warehouse and dock use.
EYEBROW:
QUICK SPEC PILLS:
Ispat Shilpi roll cage trolleys are built to perform across all these environments. Fabricated from high-tensile mild steel wire mesh on a robust wheeled base, they combine the structural integrity of an industrial container with the manoeuvrability of a wheeled trolley — allowing single-person operation across flat warehouse floors, loading docks, and retail shop floors.
The collapsible three-panel design means that when empty, the unit folds to a fraction of its loaded footprint — enabling multiple cages to be stored or transported in the space of one loaded unit. For operations running high-frequency two-way logistics (such as central-warehouse-to-store delivery), this translates directly into significant and measurable reverse freight savings.
Technical Specifications
| Material | Mild Steel Wire Mesh (High Tensile) |
|---|---|
| Load Capacity | Up to 500 kg |
| Standard Sizes | 1200×800×1600 mm (H including castors) |
| Wire Diameter | 4–6 mm (application-dependent) |
| Castor Size | 125 mm / 150 mm — specify on order |
| Castor Type | PU or Nylon; 2 swivel + 2 fixed (standard) |
| Castor Load | Rated per unit set for full cage load |
| Collapsible | Yes — 3-panel fold-flat design |
| Surface Finish | Powder Coated (standard) | Zinc Electroplated (optional) |
| Door / Access | Drop-front gate (standard) | Double-door available |
| Compliance | ISO 9001:2015 Certified |
| Custom Sizes | Yes — any dimension, mesh pitch, or castor spec available |
Key Features & Benefits
Collapsible 3-Panel Design
Folds flat in seconds. Return multiple empty cages in the footprint of one loaded unit — dramatically reducing reverse logistics costs.
Heavy-Duty Industrial Castors
125/150 mm PU or Nylon castors rated for continuous warehouse use. Swivel front for manoeuvrability, fixed rear for directional stability.
Full Mesh Visibility
Open wire mesh construction enables complete inventory visibility without opening the cage — speeding up picking and dispatch operations.
Drop-Front Gate
Enables fast, ergonomic loading and unloading at packing stations, pick lines, or retail shop floors.
Powder Coated Finish
Durable, attractive finish available in standard and RAL custom colours to match your brand or colour-coding system.
Nestable & Stackable When Empty
Folded cages can be nested and stacked for storage, minimising floor space at depots and stores.
Custom to Your Application
Dimensions, mesh pitch, door configuration, castor type, and finish configurable to your fleet requirements.
Applications & Industries
Retail Distribution
Central warehouse to store replenishment and returns management.
E-Commerce Fulfilment
Picking, sorting, and dispatch in high-throughput fulfilment centres.
FMCG Logistics
Last-mile delivery of fast-moving consumer goods to retail and distribution points.
In-Plant Material Movement
Ergonomic, manoeuvrable component and assembly transport on production floors.
Cold Chain & Food Distribution
Galvanised variants suitable for chilled and ambient food distribution.
Pharmaceutical Warehousing
Clean-profile mesh construction suitable for GMP-compliant distribution environments.
